New Induction Heating Machine for Heatment with 5p Cooling -Water Machine 40kw

New Induction Heating Machine for Heatment with 5p Cooling -Water Machine 40kw

MOQ: 1
মূল্য: 1
বিস্তারিত তথ্য
ফ্রিকোয়েন্সি:
30-80khz
কাজের অবস্থা:
ক্রমাগত
পরিবহন প্যাকেজ:
কাঠের বাক্স
স্পেসিফিকেশন:
সিই, এসজিএস, আইএসও
ট্রেডমার্ক:
ওআরডি
উৎপত্তি:
চীন
এইচএস কোড:
8514400090
উৎপাদন ক্ষমতা:
10, 000 সেট
বিশেষভাবে তুলে ধরা:

40kw induction heating machine

,

high frequency induction heater with cooling

,

induction heating machine for heat treatment

পণ্যের বিবরণ

 New induction heating machine for heatment with 5p cooling -water machine 40KW
New Induction Heating Machine for Heatment with 5p Cooling -Water Machine 40kw 0






Induction Heating Machine:

Advantage:
1 More than ten years experience,stable and goods performance
2 CE certificated
3 Copperated with ZHOUDAFU, Matsushita,Foxconn, Media, Gree a6nd ZHIGAO Air conditioner.
4 Suitable  for a large range, heating, quenching, forging, melting, solding and so on.

Main characteristics:
1 Siemens IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
2 100% Duty cycle, continuous working is allowed at maximum power output.
3Display of heating power and heating current and oscillating frequency;
4 Simple to install, Installation can be done by unprofessional person very easily;
5 Light weight
6 Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;
7 Constant current or constant power status can be selected accordingly to achieve higher heating efficiency;
New Induction Heating Machine for Heatment with 5p Cooling -Water Machine 40kw 1


New Induction Heating Machine for Heatment with 5p Cooling -Water Machine 40kw 2

 Type HF-40AB
 Work Power  3*380v/415v/440v/480v  50-60hz
 The range of operating voltage  340-430V AC
 Output power  40KW
 Input current  40A
 Fluctuating frequency  30-80khz
 Timing (Heat time,Retain time,Cool time)  1-99S
 The flow rate of cooling water  0.15 Mpa 10L/Min
 Water temperature protection point  40centidegree
 Duty cycle  100% (40degree room temperature)
 Weight  Mainparts:42Kg    Transformer:32kg
 Size Main Parts: Main Parts:640*280*550mm
Transformer: 510*260*410mm
New Induction Heating Machine for Heatment with 5p Cooling -Water Machine 40kw 3
